ALUMINIUM ROLLING STAIRCASE LADDER
FEATURES
- Fixed and fully welded.
- Wide and anti-skid step.
- Wide working platform with safety guardrail.
- Movable with lockable caster wheel.
Item Code : RSAL
Safe Working Load: 250 KGS
TECHNICAL DATA (Dimensions in MM)
| CODE | NO OF STEPS | PLATFORM SIZE | TOTAL WIDTH | BASE LENGTH | PLATFORM HEIGHT | TOTAL HEIGHT |
|---|---|---|---|---|---|---|
| RSAL2 | 1+1 | 600x650 | 850 | 765 | 500 | 1500 | RSAL3 | 2+1 | 600x650 | 850 | 910 | 750 | 1750 | RSAL4 | 3+1 | 600x650 | 850 | 1055 | 1000 | 2000 | RSAL5 | 4+1 | 600x650 | 900 | 1200 | 1250 | 2250 | RSAL6 | 5+1 | 600x650 | 900 | 1345 | 1500 | 2500 | RSAL7 | 6+1 | 600x650 | 950 | 1490 | 1750 | 2750 | RSAL8 | 7+1 | 600x650 | 950 | 1635 | 2000 | 3000 | RSAL9 | 8+1 | 600x800 | 1100 | 1780 | 2250 | 3250 | RSAL10 | 9+1 | 600x800 | 1100 | 1925 | 2500 | 3500 | RSAL11 | 10+1 | 600x800 | 1100 | 2070 | 2750 | 3750 | RSAL12 | 11+1 | 600x800 | 1100 | 2215 | 3000 | 4000 | RSAL13 | 12+1 | 600x800 | 1100 | 2360 | 3250 | 4250 | RSAL14 | 13+1 | 600x800 | 1100 | 2505 | 3500 | 4500 | RSAL15 | 14+1 | 600x800 | 1100 | 2650 | 3750 | 4750 | RSAL16 | 15+1 | 600x800 | 1200 | 2795 | 4000 | 5000 | RSAL17 | 16+1 | 600x800 | 1200 | 2940 | 4250 | 5250 | RSAL18 | 17+1 | 600x800 | 1200 | 3085 | 4500 | 5500 | RSAL19 | 18+1 | 600x800 | 1200 | 3230 | 4750 | 5750 | RSAL20 | 19+1 | 600x800 | 1300 | 3375 | 5000 | 6000 |
